Socomec SLB Load Break Switch kit, w/ External Handle, 3P 400A
Regular price
$0.00 AUD
Couldn't load pickup availability
Got questions?
Feel free to get in touch.
Price on application. Pricing on this item moves with supplier rates, so we quote it fresh rather than list a price that goes stale.
Email orders@dzelectricalproducts.com for a current price and availability. Quote the SKU shown on this page and we'll come back to you the same business day.
Component Type (ETIM Class)
Switch disconnector
Electrical
Rated permanent current at AC-21, 400 V400 A
Rated permanent current Iu400 A
Number of poles3
Rated operation power at AC-23, 400 V220 kW
Rated operation current Ie at AC-23a, 400 V400 A
Rated operation current Ie at AC-23a, 500 V315 A
Rated operation current Ie at AC-23a, 690 V160 A
Rated operation current Ie at DC-23a, 500 V400 A
Rated short-time withstand current lcw25 kA
Rated insulation voltage Ui1000 V
Rated impulse withstand voltage Uimp12 kV
Construction
Degree of protection (IP), front sideIP65
Dimensions
Height235 mm
Width210 mm
Depth165 mm
Weight4 kg
