NHP DIN-T Miniature Circuit Breaker DC 6kA 2Pole 10A C Curve
Regular price
$0.00 AUD
Couldn't load pickup availability
Got questions?
Feel free to get in touch.
Price on application. Pricing on this item moves with supplier rates, so we quote it fresh rather than list a price that goes stale.
Email orders@dzelectricalproducts.com for a current price and availability. Quote the SKU shown on this page and we'll come back to you the same business day.
Component Type (ETIM Class)
Miniature circuit breaker (MCB)
Electrical
Rated current10 A
Number of poles (total)2
Trip curveC
Rated voltage415 V
Frequency50-60 Hz
Voltage typeAC/DC
Rated ultimate short-circuit breaking capacity, Icu 125V DC10 kA
Service voltage Ub, AC12 V
Service voltage Ub, DC12 V
Nominal operating voltage Un, DC500 V
Rated short-circuit breaking capacity Icn according to AS/NZS 60898 at 230 VAC6 kA
Rated short-circuit breaking capacity Icn according to AS/NZS 60898 at 400 VAC6 kA
Rated short-circuit breaking capacity Icu according to AS/NZS 60947-2 at 400 VAC6 kA
Max. rated operation voltage Ue440 V
Rated insulation voltage Ui440 V
Rated impulse withstand voltage Uimp6 kV
Concurrently switching neutral conductorYes
Construction
Number of protected poles2
Degree of protection (IP)IP40
Mechanical
Connectable conductor cross section solid-core1-35 mm²
Connectable conductor cross section multi-wired1-25 mm²
Dimensions
Height86 mm
Width36 mm
Width in number of modular spacings2
Depth76 mm
Weight0.13 kg
Environment
Pollution degree3
Rated surrounding temperature without derating30 °C
Ambient temperature during operating-25-70 °C
