S&S CS8 Relay 24VDC Coil 4NO Contact
Regular price
₱0.00 PHP
Couldn't load pickup availability
Got questions?
Feel free to get in touch.
Price on application. Pricing on this item moves with supplier rates, so we quote it fresh rather than list a price that goes stale.
Email orders@dzelectricalproducts.com for a current price and availability. Quote the SKU shown on this page and we'll come back to you the same business day.
Component Type (ETIM Class)
Contactor relay
Electrical
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact4
Rated operation current Ie, 400 V10 A
Max. rated operation voltage Ue AC690 V
Voltage type for actuatingDC
Control supply voltage Us at DC24 V
Power consumption, DC coil pickup3 W
Power consumption, DC coil hold-in3 W
Construction
Mounting methodDIN-rail/screw
Mechanical
Connection type auxiliary circuitScrew connection
Dimensions
Height56 mm
Width45 mm
Depth53 mm
Weight0.2 kg
