NHP DIN-T Miniature Circuit Breaker 10kA 1Pole 0.5A C Curve
Regular price
£0.00 GBP
Couldn't load pickup availability
Got questions?
Feel free to get in touch.
Price on application. Pricing on this item moves with supplier rates, so we quote it fresh rather than list a price that goes stale.
Email orders@dzelectricalproducts.com for a current price and availability. Quote the SKU shown on this page and we'll come back to you the same business day.
Component Type (ETIM Class)
Miniature circuit breaker (MCB)
Electrical
Rated current0.5 A
Number of poles (total)1
Trip curveC
Rated voltage240 V
Frequency50-60 Hz
Voltage typeAC/DC
Service voltage Ub, AC12 V
Service voltage Ub, DC12 V
Nominal operating voltage Un, DC48 V
Rated short-circuit breaking capacity Icn according to AS/NZS 60898 at 230 VAC10 kA
Rated short-circuit breaking capacity Icn according to AS/NZS 60898 at 400 VAC10 kA
Rated short-circuit breaking capacity Icu according to AS/NZS 60947-2 at 230 VAC15 kA
Rated short-circuit breaking capacity Icu according to AS/NZS 60947-2 at 400 VAC4 kA
Max. rated operation voltage Ue250 V
Rated insulation voltage Ui440 V
Rated impulse withstand voltage Uimp6 kV
Construction
Number of protected poles1
Degree of protection (IP)IP40
Mechanical
Connectable conductor cross section solid-core1-35 mm²
Connectable conductor cross section multi-wired1-25 mm²
Dimensions
Height86 mm
Width18 mm
Width in number of modular spacings1
Depth76 mm
Weight0.12 kg
Environment
Pollution degree3
Rated surrounding temperature without derating30 °C
Ambient temperature during operating-25-70 °C
