Allen-Bradley 1606 Power Supply Compact 1Phase 100 to 240V AC to 24 to 28V DC 72W 3A
Regular price
£0.00 GBP
Couldn't load pickup availability
Got questions?
Feel free to get in touch.
Price on application. Pricing on this item moves with supplier rates, so we quote it fresh rather than list a price that goes stale.
Email orders@dzelectricalproducts.com for a current price and availability. Quote the SKU shown on this page and we'll come back to you the same business day.
Component Type (ETIM Class)
DC-power supply
Electrical
Voltage type of supply voltageAC/DC
Rated supply voltage at AC 50 Hz100-240 V
Rated supply voltage at DC220-375 V
Frequency50-60 Hz
Nominal current (In)0.8 A
Max. starting current30 A
1st secondary output voltage24-28 V
Max. output current 13 A
Nominal value output current 13 A
Nominal value output voltage 124 V
Power output72 W
Power consumption8.7 VA
Efficiency89 %
Type of electric connectionSpring clamp connection
With LED indicationYes
Secondary voltage adjustableYes
Rated supply voltage at AC 60 Hz100-240 V
Output voltage stabilizedYes
Construction
Rail mounting possibleYes
Wall mounting possibleYes
Degree of protection (IP)IP20
Direct mounting possibleNo
Degree of protection (NEMA)Other
Dimensions
Width45 mm
Height75 mm
Depth91 mm
Weight0.26 kg
Environment
Operating temperature-10-70 °C
StabilizedYes
